| PI 115 |
|
| General |
|---|
| Connectors | 1 RJ-45 female connector for pass-through input
1 RJ-45 female connector for pass-through and power output |
| Ethernet standards | 10/100/1000Base-T |
| Power supply | Internal
Input: 100-240 VAC, 50-60 Hz |
| Power input | |
| No load | 100 VAC to 240 VAC, 50-60 Hz, 0.45 watts |
| Full power | 100 VAC to 240 VAC, 50-60 Hz, 19.68 watts, 0.39 A maximum |
| Power output | 48 VDC, 0.35 A, 16.8 watts
Compatible with 802.3af PoE devices |
| Efficiency | |
| At full load, 230 VAC | 86.21% |
| At full load, 100 VAC | 85.77% |
| Power consumption | |
| No load | 100 VAC to 240 VAC, 50-60 Hz, 0.25 watts |
| Full load | 100 VAC to 240 VAC, 50-60 Hz, 19.68 watts |
| Ambient temperature/humidity | Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing |
| Cooling | Convection, no vents |
| Mounting | |
| Rack mount | Yes, with optional 1U rack shelf with the included ZipClip 200 mounting clip or by
securing to rack rails with tie wraps |
| Furniture mount | Yes, with the included ZipClip 200 mounting clip |
| Pole mount | Yes, using tie wraps |
| Enclosure type | High impact, high temperature plastic |
| Enclosure dimensions | 1.7" H x 4.3" W x 4.5" D (1U high, quarter rack wide)
(4.2 cm H x 11.0 cm W x 11.4 cm D) |
| Product weight | 0.6 lb (0.3 kg) |
| Regulatory compliance | |
| Safety, EMI/EMC | CE, C-tick, c-UL, UL, CISPR 32, CISPR 35, FCC Class B, NEC Class 2 |
| Environmental | Complies with the appropriate requirements of RoHS, WEEE. |
| Product warranty | 7 years parts and labor |
| NOTE | Specifications are subject to change without notice. |
|
| (5727-D3) |
